ELECTRON GRADE ZINC OXIDE

NANO-ZINC OXIDE FOR FLUORESCENCE PRODUCTS

Nano Zinc oxide for Fluorescent products
   Zinc oxide is a low-voltage electron beam of light-emitting material can be the only, light blue and red colors, the energy gap is 3.2eV, corresponding to the UV wavelength 387nm. When the nano-Zinc oxide particles by ultra-violet light, the particles of the photo-generated electrons and holes will quickly spread to the surface, in the face of complex photochemical reactions, while zinc oxide particles also have a series of reactions fluorescence occurred, using the properties of Zinc oxide fluorescent products can be prepared.

Item
Quality
Nks131
Nks132
Nks133
ZnO/% ≥
99.0
97.0
95.0
Grain size （um）
20
57
100
XRD /nm  ≤
20
52
100
Surface proportion (㎡/g)≥
60
62
65
Join index≤
50
60
100
Lead oxide( Pb )/%≤
0.0005
0.0005
0.0005
Manganese Oxide /% ≤
0.0001
0.0001
0.0001
Cupric oxide(Cu)/%≤
0.0001
0.0001
0.0001
Cd/%≤
0.0002
-
-
Hg/%≤
0.0001
-
-
As/%≤
0.0001
-
-
105℃ volatile substances %≤
0.30
0.4
0.5
Water dissoluble % ≤
0.10
0.41
0.5
Hydrochloric acid insoluble %≤
0.02
0.02
0.02
 Burning decrement ％≤
2
2
2
